PRIMUS ELITE DU-875 DISPLAY UPGRADE
Overview
Introduction
The Honeywell DU-875 display upgrade replaces old cathode ray tubes (CRT) with modern liquid crystal displays (LCD).
The Honeywell DU-875 'one-for-one' upgrade option is now available for operators wanting a lowercost, building block approach to future growth (Primus Elite & Primus Elite Advanced Features) and solve DU-870 obsolescence today. Honeywell provides a simple “plug and play” DU-875 replacement solution. The DU-875 can be installed quickly and easily in the DU-870 tray with no wiring changes.
To download the PDF Brochure for more information, please click on "Front Sheet" above.
Your needs
The DU-875 form, fit and function replacement of DU-870 is simple, fast and modular in such as the units can be replaced either by attrition or in full cockpit batches (3-5 units depending on aircraft model).
No pilot training required due to retention of current display formats, symbology and colour sets while the image quality is increased.
The DU-875 comes with a matte screen appearance to reduce glare.
DU-875 LCD technology provides superior picture contrast and resolution compared to DU-870 CRT, for enhanced pilots’ experience and situation awareness.
Weight per unit is reduced by 7lbs., no cooling system required and reliability is 2-fold that of CRT units.
Your benefits
Benefits include:
- Removes CRT obsolescence issues – Honeywell can no longer repair CRTs
- Updates cockpit to latest technology with very quick “plug and play” display replacement solution – can be done in less than a day – no downtime
- Brings brighter, clearer, high resolution picture to the pilots; runs cooler, creates less heat in cockpit
- Lowers cost of operation - increases reliability by 2X and lowers weight by seven pounds per display unit
- Operators can replace display units one at a time upon failure or all displays at once
- Positions aircraft to later add operational features, like PEEF and PEAF below, as part of Primus Elite upgrade
Product Description
System description and architecture The DU-875 is a LCD based replacement Display Unit for the CRT based DU-870. There are no changes to the existing aircraft wiring or Display Unit mounting for the direct retrofit.
The DU-875 uses a “translator” that converts existing graphics commands from the Integrated Avionics Computer (IAC) to graphics commands that are recognized by an LCD graphics generator. The DU-875 is a “smart” display containing the internal graphics engines necessary to drive the LCD screen that are controlled by the IAC HDLC display bus. The Existing Core Graphics System (CGS) commands from the IAC HDLC bus drive stroke-and-raster data into the DU-875 translator function to display legacy formats for each DU position.
Your benefits
Benefits include:
- Removes CRT obsolescence issues – Honeywell can no longer repair CRTs
- Updates cockpit to latest technology with very quick “plug and play” display replacement solution – can be done in less than a day – no downtime
- Brings brighter, clearer, high resolution picture to the pilots; runs cooler, creates less heat in cockpit
- Lowers cost of operation - increases reliability by 2X and lowers weight by seven pounds per display unit
- Operators can replace display units one at a time upon failure or all displays at once
- Positions aircraft to later add operational features, like PEEF and PEAF below, as part of Primus Elite upgrade
